Quantum Heat Pump

Call: (08) 8444 7311

Reduce your energy expenses by as much as 50% telephone Adelaide Hot Water today!

Quantum Heat Pump Hot Water

The Quantum heat pump absorb heat from the ambient air by an environmentally friendly refrigerant in the Quantum heat pump evaporator. The refrigerant gas in the Quantum heat pump is then compressed which causes the temperature of the gas to increase. The heat is then transferred to the water inside the Quantum heat pump tank.

Quantum Heat Pump Hot Water Systems feature:

  • Cuts up to 75% of Running Costs
  • No Booster Element
  • Highest Heat Pump Hot Water Recovery Rate
  • Five Year Water Tank and Integral Condenser Warranty
  • Two Year Warranty on Electrical & Refrigeration Components
  • No Solar Roof Panels
  • 150, 200, 270 and 340 Litre Capacity

With 30 years of development, Quantum have produced a heat pump that does not require a booster element and that can operate in ambient temperatures as low as -10ºc. These Quantum hot water heaters also offer the highest hot water recovery rate in the heat pump market. Adelaide Hot Water TM provide Quantum heat pump installation, servicing, repairs and maintenance. The current range of Quantum heat pump systems include the Quantum Compact 150L Heat Pump Hot Water System, the Quantum Compact 200L Heat Pump Hot Water System, the Quantum Compact 270L Heat Pump Hot Water System, theQuantum Compact 340L Heat Pump Hot Water System and the Quantum Titan Compact 340L Heat Pump Hot Water System. Do you need more information about the Quantum heat pump hot water systems? Not sure which Quantum hot water heater is right for you? Call Adelaide Hot Water TM today for specialist Adelaide heat pump plumbing advice on (08) 8444 7311.

Quantum Heat Pump Systems

quantum-heat-pump-150-litre

Compact 150L

Quantum Compact 150L Heat Pump Hot Water System

  • Small Households
  • 130 Litre (Rated Size)
  • 5 Year Cylinder Warranty
  • 1 Year Parts & Labour Warranty
  • Vitreous Enamel Cylinder
  • 10 Amps
  • External Installation

quantum-heat-pump-200-litre

Compact 200L

Quantum Compact 200L Heat Pump Hot Water System

  • Small-Average Households
  • 175 Litre (Rated Size)
  • 5 Year Cylinder Warranty
  • 1 Year Parts & Labour Warranty
  • Vitreous Enamel Cylinder
  • 15 Amps
  • External Installation

quantum-heat-pump-270-litre

Compact 270L

Quantum Compact 270L Heat Pump Hot Water System

  • Average Households
  • 250 Litre (Rated Size)
  • 5 Year Cylinder Warranty
  • 1 Year Parts & Labour Warranty
  • Vitreous Enamel Cylinder
  • 15 Amps
  • External Installation

quantum-heat-pump-340-litre

Compact 340L

Quantum Compact 340L Heat Pump Hot Water System

  • Large Households
  • 315 Litre (Rated Size)
  • 5 Year Cylinder Warranty
  • 1 Year Parts & Labour Warranty
  • Vitreous Enamel Cylinder
  • 15 Amps
  • External Installation

quantum-heat-pump-340-litre-titan

Titan Comp. 340L

Quantum Titan Compact 340L Heat Pump System

  • Extra Large Households
  • 315 Litre (Rated Size)
  • 5 Year Cylinder Warranty
  • 1 Year Parts & Labour Warranty
  • Vitreous Enamel Cylinder
  • 15 Amps
  • External Installation

Quantum Heat Pump Hot Water Systems – Technical Specifications

Quantum Heat Pump Systems from Adelaide Hot Water

Quantum heat pump technical specifications for the current systems include the Quantum Compact 150L heat pump hot water system, the Quantum Compact 200L heat pump system, the Quantum Compact 270L hot water system, the Quantum Compact 340L heat pump hot water system and the Quantum Titan Compact 340L heat pump hot water system. If you need more information about the Quantum heat pump hot water systems call Adelaide Hot Water TM today. Not sure which Quantum hot water heater is right for you? Call us today for specialist Adelaide heat pump advice on (08) 8444 7311.

Quantum Compact 150L heat pump hot water from Adelaide Hot Water.

Specifications
Model Compact 150L
Model Number 150-08ACW-134
Rated Size (Litres) 130
Heating Output (kW) 2.45
Power input (kW) 0.66
COP of heating 3.67
Compressor 16.55cc* Rotary
Refrigerant R134
Electrical supply 220-240V/50Hz/1Ph
Ciruit 10 Amps
Water connections 3 slash 4
PTR valve setting 1000kPa
ECV setting 850kPa
PLV without ECV fitted 500-600kPa
PLV with ECV fitted 350-500kPa
Operating sound level at 1.5M 50dBA
Dimensions ( Height * Diameter ) 1620 mm x 540mm
Nett (empty) weight 100 kg
Ambient air operating temperature -10 °C to +40 °C
Maximum temperature 70 °C
Water temp setting 60 °C
Hot water production rate L/hr (COP) 53 (3.67)

Quantum Compact 200L heat pump hot water from Adelaide Hot Water.

Specifications
Model Compact 200L
Model Number 200-08ACW-134
Rated Size (Litres) 175
Heating Output (kW) 2.45
Power input (kW) 0.66
COP of heating 3.67
Compressor 16.55cc* Rotary
Refrigerant R134a
Electrical supply 220-240V/50Hz/1Ph
Ciruit 15 Amps
Water connections 3 slash 4
PTR valve setting 1,000kPa
ECV setting 850kPa
PLV without ECV fitted 500-600kPa
PLV with ECV fitted 350-500kPa
Operating sound level at 1.5M 48dB (A) (*45dB(A)
Dimensions ( Height * Diameter ) 1900 mm x 650mm
Nett (empty) weight 135 kg
Ambient air operating temperature -10 °C to +40 °C
Maximum temperature 70 °C
Water temp setting 60 °C
Hot water production rate L/hr (COP) 77 (3.88)

Quantum Compact 270L heat pump hot water from Adelaide Hot Water.

Specifications
Model Compact 270L
Model Number 270-11AC4-134
Rated Size (Litres) 250
Heating Output (kW) 3.83
Power input (kW) 0.99
COP of heating 3.88
Compressor 23.1cc*
Refrigerant R134a
Electrical supply 220-240V/50Hz/1Ph
Ciruit 15 Amps
Water connections 3 slash 4 BSP – 20mm
PTR valve setting 1,000kPa
ECV setting 850kPa
PLV without ECV fitted 500-600kPa
PLV with ECV fitted 350-500kPa
Operating sound level at 1.5M 48dB (A) (*45dB(A)
Dimensions ( Height * Diameter ) 1900 mm x 650 mm
Nett (empty) weight 135 kg
Ambient air operating temperature -10 °C to +40 °C
Maximum temperature 70 °C
Water temp setting 60 °C
Hot water production rate L/hr (COP) 77 (3.88)

Quantum Compact 340L heat pump hot water from Adelaide Hot Water.

Specifications
Model Compact 340L
Model Number 340-11AC4-134
Rated Size (Litres) 315
Heating Output (kW) 3.83
Power input (kW) 0.99
COP of heating 3.88
Compressor 23.1cc*
Refrigerant R134a
Electrical supply 220-240V/50Hz/1Ph
Ciruit 15 Amps
Water connections 3 slash 4 BSP
PTR valve setting 1,000kPa
ECV setting 850kPa
PLV without ECV fitted 500 or 600 kPa
PLV with ECV fitted 350 or 500 kPa
Operating sound level at 1.5M 48dB (A) (*45dB(A)
Dimensions ( Height * Diameter ) 1900mm x 650mm
Nett (empty) weight 135kg
Ambient air operating temperature -10°C to +40°C
Maximum temperature 70 °C
Water temp setting 60 °C
Hot water production rate L/hr (COP) 77 (3.88)

Quantum Titan Compact 340L heat pump hot water from Adelaide Hot Water.

Specifications
Model Titan Compact 340L
Model Number 340-17ACW-134
Rated Size (Litres) 315
Heating Output (kW) 6.22
Power input (kW) 1.66
COP of heating 3.74
Compressor 39 cc*
Refrigerant R134a
Electrical supply 220-240V/50Hz/1Ph
Ciruit 15 Amps
Water connections 3 slash 4
PTR valve setting 1,000kPa
ECV setting 850kPa
PLV without ECV fitted 500 or 600 kPa
PLV with ECV fitted 350 or 500 kPa
Operating sound level at 1.5M 58dBA
Dimensions ( Height * Diameter ) 2300mm X 650mm
Nett (empty) weight 180kg
Ambient air operating temperature -10 °C to +40 °C
Maximum temperature 70 °C
Water temp setting 60 °C
Hot water production rate L/hr (COP) 134 (3.74)
